Dropship Copper Lug Bell Mouth 50mm² M10 Stud - 50 Pack

The Copper Lug Bell Mouth 50mm² M10 Stud - 50 Pack is an essential component for anyone working with electrical systems. These copper cable lugs are designed to provide a secure and efficient connection between electrical cables and various equipment, such as busbars and electric motors. With their high conductivity, these lugs can handle substantial currents, making them ideal for both residential and industrial applications.

Features and Benefits

One of the standout features of our Copper Lugs is their versatility. They come in a wide range of sizes, ensuring that you can find the perfect fit for your specific needs. Whether you are using a handheld crimper or a hydraulic crimper, these lugs can be easily crimped for a secure connection. The design allows for easy insertion of cables, making installation quick and hassle-free.

Specifications

Each pack contains 50 copper lugs, providing excellent value for those who require multiple connections. The conductor size is 50mm², and they are designed to fit M10 studs. The internal diameter size is 9.5mm, with a palm width of 19mm and a barrel length of 22mm. The full length of each lug is 49mm, and the A/F hex size is 10.4mm. Made from Copper Grade C11000, these lugs are built to last.

Conductive Material

Our Copper Lugs are made from 99.9% pure copper, ensuring maximum conductivity. The oxygen content is kept at 30, and the tensile strength is a minimum of 205 Mpa. The lugs are fully annealed, providing excellent ductility with a rating of 40%. The electroplating material used is tin, also at 99.9% purity, which enhances the durability of the lugs. The thickness of the electroplating ranges from 5 to 10 microns, ensuring long-lasting performance.

Electrical Properties

These lugs boast a total conductivity of 99.9% IACS, making them highly efficient for electrical applications. The total resistivity is measured at 1.72 micro-ohm cm, which is excellent for minimizing energy loss in electrical systems. Additionally, they can operate in a wide temperature range from -55°C to 155°C, thanks to the use of oxygen-free copper.

Compliance and Standards

Our Copper Lugs comply with the Australian and New Zealand standard AS/NZS4325 Part 1:1995, ensuring that they meet the necessary safety and performance requirements. This compliance guarantees that you are using a product that is trusted and reliable for your electrical needs.
